Home > Product Categories > NON WOVEN T-SHIRT BAG MAKING MACHINE

NON WOVEN T-SHIRT BAG MAKING MACHINE Favorites

Raw material: Place of Origin:Wenzhou
Condition: New Loading Port:
Product description:NON WOVEN T-SHIRT BAG MAKING MACHINE
Ruian Wanyuan Packaging Machinery Co.,Ltd
Company type: Manufacturer Credit:
Main products:manufacturer of non woven and plastic bag making and printing machinery(nonwoven bag making machine, flexo printing machine, lamination machine, plastic bag making machine, folding machine,)
Get Quotation

Nonwoven Bag Making Machine-T-Shirt Bag



DESCRIPTION:

This machine can produce non woven bags of various size and shapes, such as non woven shopping bags, shoes bag, and other packaging bags with shapes like D-cut, U-cut and so on.

1. PLC control, bag length can be set according to different requirement.

2. Magnetic Brake for tension control. Equipped with EPC device.

3. Dual step motors to make bag more smoothly and avoid waste

4. Photocell tracking for fabric with printing.

5. Automatic pneumatic Die cutting and temperature control.

6. Automatic stop when fabric runs out.

7. Easy operation, electric power saving, perfect bag forming



Technical Parameters:

Type

WY-ZB600

WY-ZB700

WY-ZB800

Production Speed

20-100pcs/min

20-100pcs/min

20-100pcs/min

Bag-making Width

100-800mm

100-800mm

100-800mm

Bag-making Length

200-520mm

200-620mm

200-720mm

Bag-making Thickness

15-50g

15-50g

15-50g

Power Supply

380v/220v

380v/220v

380v/220v

Total Power

8kw

10kw

12kw

Overall Dimension(LxWxH)

9600x1500x1800mm

9600x1700x1800mm

9600x1800x1800mm
